GeoSLAM ZEB Go Handheld 3D Scanner - Sale! (Used)

GeoSLAM ZEB Go Handheld 3D Scanner

Handheld 3D laser scanning made simple

This state-of-the-art scanning technology allows you to take geospatial measurements quickly, easily and with accuracy you can rely on. It’s a small and portable 3D scanner using LiDAR technology.

The ZEB Go is your first step in SLAM handheld 3D scanning technology. It’s user-friendly and captures great quality data at high speed. Whether it’s the first time you’ve looked at digital surveying, or you want each of your sites equipped with the smartest SLAM, the ZEB Go is the solution for you.

Handheld Laser Scanning For Everyone

If you're looking for a reliable way to map and understand spaces, the ZEB Go is made for you. The ZEB Go is your first step in SLAM handheld technology - whether it's the first time you've looked at LiDAR for digital surveying or you want each of your sites equipped with the smartest tech, the ZEB Go is the place to start.

Powered By The Smartest SLAM

With one button operation, you'll be up and running fast - capturing survey grade data in minutes. Process a point cloud quickly using the intelligent point cloud processing platform GeoSLAM Connect. GeoSLAM data is compatible with software that works for you with universal file formats (LAZ/LAS/PLY/TXT/e57)

SPECS:

GENERAL

Total Weight [kg]2.65

Year of introduction2020

Hardware MaterialScanner- aluminium body, plastic handle. Datalogger- aluminium.

SCANNING CHARACTERISTICS

Light sourceActive

Max. Range [mm]30000

Max. vertical field of view [deg]360

3D measurement accuracy [mm]10-30

Data aquisition speed (points p/second)43000

Laser ClassClass 1 / λ 905nm

Max. horizontal field of view [deg]270

Color registrationY

Scanning Speed40Hz

wavelength light source [nm]905

POWER

Scan time per battery [h]1.5

Battery typeLi-Ion

FUNCTIONALITY

Software nameGeoSLAM Connect

Real time visualization during scanning

APPLICATION

Main usersconstruction, forestry, engineering, architecture, mining, education, geospatial, security, defence

MORE INFORMATION

Distinguishable featureshandheld, light-weight

CONNECTIVITY AND SENSORS

USB Port: Y

WiFi: N

Bluetooth: N

OPERATION CHARACTERISTICS

Operating temperature: min. [°C]0

Operating temperature: max. [°C]50

Humidity range [%]<85%RH

INCLUDES:

ü ZEB Go Scanner

ü ZEB Go Data Logger (inc. 12V battery)

ü 12V Battery Charger

ü ZEB Main Cable (1.5m length)

ü Ethernet Cable (1.5m length)

ü USB Memory Stick

ü Reference Base

ü Phone Holder

ü Shipped in a Soft Carry Case

ü GeoSLAM Connect and GeoSLAM Care come STANDARD with every ZEB scanner

ü GeoSLAM Connect Software

ü 1-year Hardware Warranty when a valid GeoSLAM care package is in place
